JinkoSolar has introduced a 510 W all-black residential solar module based on its new TAC cell technology. The dual-glass panel features a reported efficiency of 25.52%, a power density of approximately 255 W/m² and a 40-year product and performance warranty.
Chinese solar module manufacturer JinkoSolar has unveiled a 510 W all-black residential solar panel based on its newly introduced TOPCon-based Amorphous-Si Passivating Cell (TAC) technology, which combines TOPCon electron-selective contacts, amorphous silicon heterojunction passivation and a back-contact electrode architecture.
The JKM485–510T series targets premium residential applications, including villas and homes with limited rooftop space, where power density, aesthetics and long-term reliability are key considerations.
The company said the 48-cell Tiger Neo 5.0 module has a maximum power conversion efficiency of 25.52% and a monofacial, dual-glass design. It measures 1,762 mm × 1,134 mm × 30 mm, weighs 22 kg and offers a maximum power density of approximately 255 W/m².
JinkoSolar said it has integrated several technologies to increase module power density and improve aesthetics. Its Gapless Cell Array (GCA) technology eliminates conventional gaps between cells, while concealed interconnections and busbars reduce inactive areas. According to the company, the design increases the effective light-receiving area by approximately 2%, resulting in an additional 10 W of module output.
The module also features Uniform Matrix Interconnection (UMI) technology, which replaces conventional printed main busbars with distributed electrical connections. JinkoSolar said the architecture shortens current paths, reduces resistive losses and enables interconnection processes that place less mechanical stress on the cells.
For improved aesthetics, the manufacturer has incorporated its All Consistent Color (ACC) technology, which combines precise control of coating thickness and refractive index with AI-assisted cell sorting. The process is designed to minimize visible color variations between cells, encapsulation materials and the frame, resulting in a more uniform black appearance.
The panel also uses Full-Spectrum Light Trapping (FLT) technology, combining surface texturing, antireflective coatings and rear-side reflection to improve light utilization under oblique sunlight and low-irradiance conditions.
The module features a power temperature coefficient of -0.24%/C, compared with approximately -0.26%/C for JinkoSolar’s previous TOPCon products. The manufacturer also claims the new panel delivers around 30 W more power than conventional back-contact modules of comparable dimensions.
For reliability, JinkoSolar has integrated a Perimeter Moisture Barrier (PMB) featuring butyl-based edge sealing to reduce moisture ingress and the associated risk of corrosion. The module also incorporates an optimized current-shunting design intended to limit power losses and reduce hot-spot risks under partial shading.
JinkoSolar offers a 40-year product warranty and a 40-year linear power output warranty for the module, according to its technical documentation.
“Our vision for Tiger Neo 5.0 was to develop a panel tailored to premium residential rooftops,” said JinkoSolar CEO Charlie Cao.
The new residential panel expands JinkoSolar’s Tiger Neo 5.0 portfolio, which includes larger-format TOPCon modules introduced in June 2026, with power outputs exceeding 700 W and efficiencies of up to 25.91%.
JinkoSolar has identified Europe and Australia as target markets for residential applications. The company has not yet disclosed commercial availability, pricing or production volumes for the new TAC-based module.
