Bitcoin Optech Newsletter #427

This week’s newsletter summarizes the disclosure of two denial-of-service vulnerabilities in older versions of Eclair and describes a proposed scheme for running complex multi-round contracts inside Lightning channels. Also included are our regular sections announcing new releases and release candidates and describing notable changes to popular Bitcoin infrastructure software.

News

• ● Disclosure of two DoS vulnerabilities fixed in Eclair v0.14.1: Erick Cestari posted to Delving Bitcoin the responsible disclosure of two denial-of-service (DoS) vulnerabilities in the channel opening process of Eclair v0.14.0 and earlier. Both were fixed in Eclair #3324 and released in v0.14.1 in July, and users running an older version should upgrade.

  The first, found by Matt Morehouse with his smite fuzzer, is a race condition in a duplicate temporary_channel_id check. Eclair checked whether the ID was already in use before accepting an open_channel message, but did not record the new channel until a later step, so an attacker sending several identical open_channel messages in quick succession could get two past the check. Eclair then created two channel states for one ID, and the second replaced the first, leaving an unreachable channel state that held about 25 kB of memory until the peer disconnected. Repeating the attack leaked about 1 MB per second until the node ran out of memory or spent all of its CPU on garbage collection.

  The second, found by Cestari, bypasses Eclair’s limit on the number of pending channels whose funding transaction has not confirmed. The duplicate check only looked at temporary IDs, so an attacker could start opening a channel, then reuse that channel’s final channel_id as the temporary_channel_id of the next open_channel. The limiter counted the reused ID twice and dropped both entries once the new channel received its final ID, so its count never rose above two while the number of pending channels grew without bound. Each pending channel stores a copy of the peer’s init features, and setting a single unknown odd feature bit at a very high position inflated that copy to about 65 kB. In Cestari’s test, one connection with no onchain cost exhausted a node’s 4 GB of memory in about 48 minutes. Because pending channels are written to the database, the node crashed again on every restart until its memory limit was raised or the rows were deleted by hand.

  Replying to a question, Morehouse noted that mobile wallets that use an Eclair node as their LSP, such as Phoenix, are unaffected because ACINQ patched its nodes months ago.

• ● Offchain contracts in Lightning channels: Adam Gibson posted to the Bitcoin-Dev mailing list about a proposal for protocol, called LN-GAP, to run complex, multi-round, two-party contracts inside a Lightning channel while settling disputes onchain in a constant number of transactions. In order to showcase the proposal, Gibson implemented a game of chess, which he deems a good example of a game that is difficult to run onchain, in which the winner takes the whole pot. Both a repository and a paper for the proposal are available.

  Two players, Alice and Bob, agree on a certain set of rules. Each player makes their own moves. In case of a dispute, Alice can enforce the rules onchain. However, Gibson notes that Lightning can enforce rules about a published state, but it cannot do so in case a counterparty stalls or stops responding. To address this issue, Gibson introduces a venue, a committee of members whose role is to attest whether a signed message (a move in a chess game and its signature) was published before a certain deadline or not. The venue only needs to attest the timeliness of the publication, not the content of the message. In case of a dispute, Alice posts a transaction claiming that no event was published by Bob; in turn, Bob can post a second transaction containing a rebuttal (his move and the venue’s attestation); finally, Alice can post a disproof, stating that Bob’s rebuttal doesn’t stand due to the event not being compliant with the rules.

  In Gibson’s proposal, the venue never holds users’ funds. Moreover, it avoids relying on FROST-style threshold signature in order to make fraud attributable only to malicious members. To do so, attestation is done through per-member “one-bit signatures” checked using OP_CHECKSIGADD. Members are incentivized by fees paid atomically over channels using adaptors. However, the construction relies on an honest-majority assumption. If more than half of the members of the venue collude with one of the parties involved, funds can be stolen.

  Other than games, possible applications include proof-of-storage contracts, where a provider forfeits a bond for failing to respond to a challenge, and offchain dispute resolution similar to what BitVMX-style zero-knowledge verifiers do onchain.

Releases and release candidates

New releases and release candidates for popular Bitcoin infrastructure projects. Please consider upgrading to new releases or helping to test release candidates.

• ● Bitcoin Core 32.0rc4 is a release candidate for the next major version of the predominant full node implementation. A testing guide is available.

Notable code and documentation changes

Notable recent changes in Bitcoin Core, Core Lightning, Eclair, LDK, LND, libsecp256k1, Hardware Wallet Interface (HWI), Rust Bitcoin, BTCPay Server, BDK, Bitcoin Improvement Proposals (BIPs), Lightning BOLTs, Lightning BLIPs, Bitcoin Inquisition, and BINANAs.

• ● Eclair #3396, #3397, and #3400 fix several ways a malicious channel peer could prevent Eclair from enforcing HTLCs onchain during splicing (see Newsletter #423). Previously, a peer could make Eclair sign a splice transaction that could not be published promptly by choosing a distant absolute locktime, adding inputs with relative timelocks, providing nonstandard witnesses, exceeding the standard transaction weight limit, or setting the signed transaction’s feerate too low. The first PR adds checks for these cases. The second makes Eclair retry commitment and penalty transactions that were rejected by a conflicting unconfirmed transaction, as the peer may later replace that transaction through RBF by double-spending one of its other inputs. The retry fix also applies when the channel’s funding transaction is unconfirmed, including zero-conf channels. The third fixes another recovery gap: if an RBF replacement of a splice confirms after Eclair force-closes using a commitment for a sibling attempt, Eclair now recognizes that the funding transaction has changed and broadcasts a commitment transaction that spends the confirmed splice output. Previously, funds could remain locked and HTLCs unenforced.

• ● Eclair #3399 and #3394 fix two ways on-the-fly funding could leave Eclair paying a downstream peer without collecting the corresponding incoming HTLC (see Newsletter #419). Previously, after Eclair stopped tracking an expired payment, a new payment could reuse its payment hash. If the downstream peer then claimed the original outgoing HTLC onchain, revealing the preimage, Eclair could mistakenly fulfill the newer payment’s incoming HTLCs instead of the original ones, allowing the original incoming HTLCs to time out without paying Eclair. The first PR now checks if a settlement belongs to the currently tracked payment and, if not, it uses the incoming HTLC details retained with the settlement to fulfill the correct HTLCs. The second PR ensures that funded payments are only forwarded over the channel where liquidity was purchased. Previously, Eclair could forward over another channel with the same peer, but would only check the funded channel before failing upstream at expiry, even though the outgoing HTLC on the other channel remained claimable.

• ● Eclair #3395 fixes a bug where a spender could construct a malformed payment onion packet with a valid HMAC that left an incoming HTLC unresolved. The spender could encode a per-hop payload length larger than the packet’s actual capacity while still providing a valid HMAC. Previously, Eclair did not validate the length before extracting the next HMAC, causing an uncaught exception. The relayer would then resume without failing the HTLC, and the malformed packet could also prevent HTLC cleanup from initializing after a restart. Now, Eclair checks that the per-hop payload, including its HMAC, fits within the packet. If it does not, Eclair returns InvalidOnionVersion, allowing normal failure handling.

• ● Eclair #3401 fixes a bug that could cause a forwarding node to lose funds after a disconnection. Eclair stores instructions to fulfill or fail HTLCs until the corresponding channel updates are signed, allowing them to be retried after reconnection. Previously, if a duplicate or conflicting instruction was rejected because a fulfillment had already been proposed but not signed, Eclair scheduled the deletion of the original stored instruction. If the channel disconnected before signing, the unsigned update was discarded, leaving no instruction to replay the fulfillment. The incoming HTLC could then time out even though the outgoing HTLC had already been fulfilled. Eclair now retains the original instruction until the settlement is signed.

• ● LDK #5080 fixes a bug where restarting during cooperative channel close could prevent pending HTLCs from being failed back to their upstream peer. Previously, when LDK restarted, it excluded channels undergoing cooperative close from the lookup used to process HTLCs, even though those channels could still have unresolved payments. Consequently, when a downstream peer failed an HTLC, LDK could mistakenly treat the upstream channel as nonexistent and discard the failure. LDK could also drop incoming HTLCs awaiting onion decoding. This could leave HTLCs unresolved until the upstream peer force-closed the channel at expiry. LDK now includes channels undergoing shutdown when restoring the information needed to resolve existing HTLCs.

• ● LDK #5087 fixes a potential privacy leak in onion messages sent over blinded paths that use dummy hops (see Newsletter #370). Dummy hops are additional encrypted layers that the recipient processes to obscure its position in the path. Previously, forwarding hops rejected intermediate onion layers containing message-content TLV records, but dummy hops accepted them. A malicious sender could insert these records at different, nonfinal layers and observe whether the final message produced a response, potentially revealing where the actual forwarding ended and the dummy hops began. LDK now rejects message-content records at dummy hops as well.

• ● LND #11068 fixes a missing check for auxiliary HTLC signatures on experimental taproot overlay channels used for Taproot Assets (see Newsletter #324). In these channels, a Taproot Assets signer (tapd) provides an additional signature entry for each non-dust HTLC alongside the usual Bitcoin signatures. Previously, if a peer sent a commitment containing the required Bitcoin signatures but omitted some or all of the auxiliary HTLC signature entries, the receiving LND node would incorrectly accept it. If the channel is later force-closed, the missing signatures could prevent the affected asset HTLCs from being resolved onchain. LND now verifies that the number of received auxiliary signature entries matches the number of non-dust HTLCs. If they differ, LND rejects the commitment and force-closes the channel.

• ● Rust Bitcoin #6956 introduces a ScriptCode type for the script data used in legacy and segwit v0 signature hashing, which may differ from the full script being spent. According to BIP143, when a P2WSH script contains OP_CODESEPARATOR, signature hashing excludes everything up to and including the last separator executed before the signature check, while retaining any subsequent separators. Previously, p2wsh_signature_hash accepted a witness script, which could lead callers to hash the complete script and produce an invalid signature. The API now accepts ScriptCode, but callers must still identify the last executed separator and shorten the script themselves. The PR also adds P2wpkhScriptCode, a fixed-size, allocation-free representation of the standard script used to sign P2WPKH inputs.

• ● BDK #2319 fixes a bug where an Electrum-backed wallet could lose track of a transaction’s confirmation after a reorg if the same transaction was mined again at the same height. BDK could retain the displaced block’s header in its cache and fail to recognize the transaction’s confirmation in the replacement block, incorrectly showing it as unconfirmed. The fix refreshes the header cache with newly fetched block headers during synchronization, including after a one-block reorg.
